Orbea Terra H40 Gravel Bike 2022
Matching value with performance, the Orbea Terra H40 Gravel Bike features a hydroformed and triple-butted aluminium frameset for durability across all terrain. Although less exotic than the more premium carbon editions, the aluminium frame is exceptionally lightweight and features confidence-inspiring geometry to offer versatility across a multitude of surfaces. Lively and fast, the frame is rigid for rapid acceleration, and the carbon fork damps vibration to reduce fatigue on longer rides.Â
Designed to eliminate chainslap for a near-silent ride, the GRX 10-speed drivetrain features a rear derailleur with an integrated stabiliser mechanism, providing additional chain security on rough terrain. Hydraulic disc brakes offer phenomenal stopping power and excellent modulation, while the Orbea Ready GR wheels utilise Shimano hubs for proven, reliable performance. 38c Vittoria tyres enhance comfort and traction when riding on looser surfaces, and the flared handlebars feature a wider width to improve stability.Â
Highlights
- Versatile gravel-specific geometry
- Orbea hydroformed, triple-butted aluminium frame is lightweight and responsive
- Full carbon fork damps vibration to reduce fatigue on rough terrain
- Wide tyre clearance allows the use of different tyre widths to suit the terrain
- Integrated mudguard mounts offer all weather protection
- 10-speed Shimano GRX groupset is reliable and supplies excellent chain retention
- Shimano RX400 hydraulic disc brakes offer powerful stopping power
Technical Specification
| Frame | Orbea Terra Hydro disc, hydroformed triple butted aluminium, tapered 1-1/8″ – 1,5″, BB 68mm – BSC English, thru-axle 12mm x 142mm rear, thread M12x P1.5, DT internal cable routing, 27.2mm seat tube, MMS system |
| Fork | Orbea Terra OMP carbon disc fork, full carbon steerer, tapered 1-1/8″ – 1,5″, carbon dropouts, thru-axle 12mm x 100m, thread M12xP1.5, MMS system |
| Headset | FSA 1-1/8 – 1-1/2″ Integrated Carbon Cup ACB bearings |
| Stem | Orbea OC1 31.8mm interface -6º |
| Handlebar | Orbea OC1 All Road, reach 80mm, drop 125mm, flare 12º |
| Front Brake | Shimano RX400, hydraulic disc |
| Rear Brake | Shimano RX400, hydraulic disc |
| Brake Levers | Shimano RX400, hydraulic disc |
| Front Derailleur | Shimano GRX RX400 |
| Rear Derailleur | Shimano RD-RX400, 10-speed |
| Shift Levers | Shimano ST-RX400, 10-speed |
| Cassette | Shimano Tiagra HG-500 11-34t, 10-speed |
| Crankset | Shimano GRX RX600-10, 30×46 teeth chainrings |
| Chain | KMC X10 |
| Front Wheel | Ready GR, 700c |
| Rear Wheel | Ready GR, 700c |
| Front Tyre | Vittoria Terreno Dry Gravel G2.0 TNT, 700x38c, tubeless-ready |
| Rear Tyre | Vittoria Terreno Dry Gravel G2.0 TNT, 700x38c, tubeless-ready |
| Saddle | Selle Royal Seta RS |
| Seatpost | Orbea OC2 27.2 Offset 20 |
| Pedals | Available to be purchased separately |
Built, Checked, Tuned and Tested
All our bikes are fully built, checked, tuned and tested by our Cytech qualified mechanics and then securely packaged, ready for delivery. All you have to do is add the pedals (if included), attach the handlebars to the stem and tighten them following the included detailed instructions or by watching our video and using the provided FREE tools. Visit our Bike Assembly page to see how you assemble your new bike once you receive it.
All bikes collected from our shop, are built, tested and ready to ride.
Please note, occasionally, manufacturers may change the specification without notice. Bicycles do not come with pedals unless otherwise specified. Bikes ordered for delivery will not arrive with the pedals installed, please refer to the owners manual and pedal installation guides provided for guidance. We do not install accessories to bikes, including mudguards. Bikes ordered for delivery that have tubeless compatible tyres and rims will arrive with inner tubes installed or with tubeless valves installed, this will be brand dependent. Sealant is available to be purchased separately.
If you require any assistance please contact our Customer Care team.
| colour | Black/Orange, Copper, Mango |
|---|---|
| Size | XS, S, M, L, XL, XXL |
